6060 Advertising Hobby CNC Router at Cheap Machine Price in Bahrain, UK
☆This is one of the most popular small cnc router in China. With DSP A11 control system, it is easy to operate even for beginners. And the movable table can much better finishe wooden figures. Moreover, all configurations can be customized according to your requirements.
CNC Router Machines Video
Features
- 1. The effective working area is 600*600mm, which can also be customized or changed for your favor.
2. With 450A steooer motor and Leadshine M542 driver, it can keep high processing accuracy and efficiency.
3. Adopts the water mist cooling sprayer, it can better cool down the spindle heat during the processing.
Parameters
| Descriptions | Parameters |
| 1. Model | ELECNC-6060 |
| 2. Working area | 600*600*130mm |
| 3. Control system | DSP A11 control system |
| 4. Spindle | 2.2kw Changsheng water cooling spindle |
| 5. Spindle speed | 0-24000rpm/min |
| 6. Motor | 450A stepper motor |
| 7. Driver | Leadshine M542 driver |
| 8. Working speed | 12m/min |
| 9. Inverter | 2.2kw Fuling Inverter |
| 10. Table surface | T-slot working table, table moving |
| 11. Linear rail | TBI ball screw and ABBA 20# linear square guide |
| 12. Control box | Inner box |
| 13. Rotary device | optional |
| 14. Mist cooling sprayer | Water mist cooling sprayer with water tank |
| 15. Tool sensor calibration | Simple tool sensor calibration |
| 17. Working voltage | 220V, 1phase, 50Hz |
Application
Wood: redwood classical and antique furniture, wood carving, gifts wooden box engraving, redwood jewelry boxes, ink-stone cutting, decorative products sculpture, fine jewelry carving and some others;
Letter cutting,sign engraving: Makes all models. Such as company plate, sings, building models, emblem, badge, display panels, fair signs, building numbers, signs of decoration, furniture and others.
